High performance high quality VOCs Catalyst
VOC Catalyst Introduction:
VOC noble metal catalyst has the characteristics of high activity at low temperature and low ignition temperature, and its resistance to S is also stronger than that of metal oxide catalyst. The activities of Pt and Pd on different reactants are different, and Pd is superior to Pt in the oxidation of CO, CH4 and olefins; For aromatics oxidation, the two are equivalent; For the oxidation of straight chain alkanes above C3, Pt is better than Pd. The order of activity of noble metal catalysts for VOC catalytic oxidation is ethanol>acetaldehyde>aromatic>ketone>acetate>halohydrocarbon>alkane.
Project customization for different gas condition, replacement project for other international brands
| Quick Detail: | ||||||
| 1. Precious metal content, from 0.2 g/L to 3 g/L | ||||||
| 2. Selection of coating amount: 0.15 g/L, 0.3 g/L, 0.5 g/L, 0.75 g/L and 1.0 g/L. | ||||||
| 3. The removal efficiency is as high as 99.9% | ||||||
| 4. Airspeed up to 30000 1/h | ||||||
| 5. Ultra-long design life > 5 years | ||||||
| 6. Starting temperature > 200℃ | ||||||
| 7. Recommended temperature: 200℃ -650℃ | ||||||
| 8. Ultra-long design life > 5 years |
| Specifications: | ||
| 1 | Conversion Rate | >98% |
| 2 | Service life | 1-4 years |
| 3 | Space Velocity | 10000~35000h-1 |
| 4 | Failure rate | <1% |
| 5 | Appearance | Yellow/black/brown |
| 6 | Packaging | seal |
| 7 | highest operating temperature | 750℃ |
| 8 | Substrate Material | Cordierite |
| 9 | Thermal expansivity(%) | 1.6-1.8 |
| 10 | Compressive strength(MPa) | Lengthways >13； Side direction>5 |
| 11 | Specific surface area of coating(m2/g) | 120-180 |
| 12 | Initiation temperature | >180℃ |
| 13 | Optimum operating temperature | 300~750℃ |
| 14 | Water absorption | 20%~28% |
| 15 | Bulk density (kg/L) | 650-750 |
| 16 | Wall thickness | <0.2mm |
| 17 | Density(g/cm3) | 0.5 |
| 18 | Tolerance | +/-1mm |
When using VOC catalysts, it is necessary to pay attention to the following safety instructions and precautions:
1. Catalysts should be stored in a dry, ventilated, and dark place, avoiding direct sunlight and humid environments;
2. During operation, protective gloves and glasses should be worn to avoid catalyst contact with skin and eyes;
3. Catalysts should avoid contact with harmful substances such as strong acids, bases, and oxidants to avoid accidental reactions;
4. During the use of catalysts, attention should be paid to controlling the catalytic temperature and gas flow rate to avoid excessive catalytic temperature and gas flow rate causing catalyst deactivation or dangerous side reactions;
5. Catalysts should be regularly inspected and maintained, and if damaged or ineffective, they should be replaced in a timely manner;
6. The catalyst should be properly disposed of after use to avoid environmental pollution or safety hazards;
7. Before using VOC catalysts, carefully read the product manual and safety instructions, and follow relevant operating procedures and safety measures.
FAQ
Q1. What is your sample policy?
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.
Q2. Do you have any MOQ limit for order?
A: Low MOQ, 1pc for sample checking is available.
Q3. How to proceed an order ?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q4. Is it OK to print my logo on product?
A: Yes. Please inform us formally before our production.
Q5: Do you offer guarantee for the products?
A: Yes, we offer 3 years warranty to our products.
Q6: How to deal with the faulty?
During the warranty period, the catalyst shall be guaranteed to operate normally within the design range. If it cannot operate normally, it shall be returned and replaced free of charge
